  • Explosion duct TD 800-200 EX

The Symbol : 9040115572

The TD 200 EX explosion-proof fan meets the requirements of the ATEX Directive 2014/34/EU, they are designed for use in explosion hazard zones outside mines and mine workings. They meet the requirements of Group II Category 2G - Zone 1. Model Td 800 200 EX

2965.00
opak Add to wishlist
Reviews
Shipping within 24 hours
Shipping price The Lack Of
The Availability Of Duża dostępność
The Weight Of The 4 kg
EAN 8413893281821

Phone order: +48606376838

DUCT FAN TD 800-200 EX EXPLOSION-PROOF FROM S&P

USE

TD EX fans meet the requirements of ATEX Directive 2014/34/EU and are designed for use in explosion hazard zones outside mines and mine workings. They meet the requirements of Group II Category 2G - Zone 1.

ATEX marking:

  • II 2G Ex e IIC T3 Gb,
  • or: II 2G Ex eb IIB T3 Gb (depending on model)
  • CONSTRUCTION
  • The TD-800/200 ATEX is made of antistatic plastic
  • Other models are made of steel sheet protected with a black polyester coating
  • high-efficiency screw rotor
  • operating temperature range from -20°C to 40°C
  • ELECTRIC MOTOR
  • 1-phase 230V, 50Hz suitable for use in hazardous areas
  • IP44 (models 1100/250 and 1200/315), IP54 (model 800/200), insulation class B
  • not suitable for speed control

Specifications:

Status:
New
Waga produktu z opakowaniem jednostkowym:
8
Diameter:
200
Typ:
Duct fan
Średnica otworu (mm):
200
Packaging Condition:
oryginalne
Energy efficiency class:
A
